Elevate Your Lifestyle with German Precision
Quartz‑i Home Elevator by Wittur
IS 15259 compliant | Single phase power | Zero hassle installation
The smartest choice for villas, duplex/triplex penthouses and G+6 buildings. Silent, safe, senior-friendly and fully customisable – with lift licence approval made easy.
Key Features
Designed for comfort, accessibility, customization, and long-term reliability.
Flexibility
Fits civil/structural shafts with minimum disruption.
Ride & Comfort
Ultra-smooth start/stop with silent operation.
Accessibility
Wide doors, reachable buttons, handrails, ARD support.
Customization
Colours, stainless finishes, glass cabins/doors, panels.
Quartz‑i Advantages
Practical engineering that improves comfort, efficiency, installation speed, and compliance.
Energy
LED lights, reduced energy consumption, standby optimization.
Comfort
Gearless machine + integrated VVVF drive for quiet travel.
Quick install
Optimized packing, manuals, plug-and-play controllers.
Compliance
IS 15259 + National Building Code alignment.
Stellar Door Features
Reforged, reinvented, and reborn with advanced durability, seamless installation, and long-lasting performance.
IS17900 Compliant
Built to meet IS17900 standards for enhanced safety, reliability, and quality assurance.
2 Million Life Cycle
Engineered for high-performance operation with an extended lifecycle of up to 2 million cycles.
Effortless Installation
Designed for quick and smooth installation, minimizing downtime and simplifying setup.
Enhanced Durability
Reinforced construction ensures superior strength, long-term durability, and dependable performance.
Visualize your perfect elevator with our interactive 3D experience
Elevator Options
Choose the right structure type based on your space, aesthetics, and site conditions.
Quartz – i Ascend
Quartz - i Elevate
Quartz – i Pinnacle
Specifications Overview
QUARTZ‑I is designed to fully comply to Indian Standards and Codes.
Designed to fully comply to Indian Standards and Codes
| Specification | Details | IS 15259 |
|---|---|---|
| Capacity | 4p | |
| Load, Kg | 272 | |
| Speed, mps | 0.15 & 0.2 | |
| Stops | 4 | |
| Travel, mtr | 12 | |
| Low pit, 300mm | Mechanical Stopper |
Quartz-i Feature Comparison
| Features | Quartz - i Ascend | Quartz - i Elevate | Quartz - i Pinnacle |
|---|---|---|---|
| Dual Emergency ARD | Yes | Yes | Yes |
| Fire Rated Doors | Yes | Yes | Yes |
| Manual Rescue (Pull lever) | Yes | Yes | Yes |
| Self Lubricating Ropes | Yes | Yes | Yes |
| Speed | 0.4m/s | 0.4m/s | 0.4m/s |
| Power Supply | 230 V | 230 V | 230 V |
| Capacity | 408 Kg | 408 Kg | 408 Kg |
| Cabin Size Max | W 1200 mm*D 1600mm | W 1200 mm*D 1600mm | W 1200 mm*D 1600mm |
| Machine Type | PMSM Gearless | PMSM Gearless | PMSM Gearless |
| Motor Warranty | 1 year | 5 years | 10 years |
| Cabin Finish Customization | Standard | Yes | Yes |
| Biometric Authentication | — | Password On COP | Facial Recognition |
| Smart Display | — | Yes | Yes |
| App Controlled | — | Yes | Yes |
| Custom User Interface | — | — | Yes |
| Alexa / Siri Interface | — | — | Yes |
| SOS Feature | — | — | Yes |
| Remote Diagnosis | — | — | Yes |
Specifications
Here is the corrected and properly organized version of the Specifications section.
Technical Data Controller
Built for quick installation and easy diagnosis.
- Compact and slim service panel
- Service Controller beside the top landing door in SS finish
- Shaft Controller inside the shaft on top floor
- Automatic evacuation function with indication on COP
- Down collective, full collective (Optional)
- The Plug-and-play controller with CAN-bus-technology for quick installation
- Pre-wired travelling cable
- Landing operation panels and car operation panels pre-wired and plug-in-type
- Automatic car light off
- Hand held terminal for easy programming and diagnosis
- Automated testing (Daily/Weekly) of ARD
Drive Technology
Smooth performance with flexible entrance support.
- Field-oriented frequency Drive integrated into controller cabinet for a smooth drive
- Programming via graphical keypad directly connected to the controller
- Supports Single/Dual entrances (Through Car)
- Dual entrances can be operated independently
Cabin Finishes
QUARTZ‑I is designed to fully comply to Indian Standards and Codes.
Standard Finishes
RAL 7035H*
00304 - No. 4
304M
EXP01 Vertical silver
SP 074 - HCSS
Special Finishes
SP 003 - Golden Mirror
SP 011 - Leather
SP 020 - DL7E
SP 032 - Bronze No. 4
SP 034 - Bronze Mirror
SP 001 - Honey comb
SP 006 - Checks
SP 007 - Linen
SP 009 - Moon rock
SP 012 - Black mirror
SP 047 - Black hairline
Floor Finishes (PVC Floor Mat)
SP 025 - Wood finish
SP 026 - Shadow white
SP 027 - N Blue
Details & FAQ
Quick answers to common questions about installation, usability, and support.
Want a site assessment & quote ?
Share your floor count, preferred cabin style, and city. Our team will guide you through feasibility and configuration.
